2000万像素8mm大景深FA镜头C Mount

物距Working Distance

倍率Optical Magnification

视野   1.1"Field of View(mm)

型号Model

HK0814MP20

mm

X

H

V

相机靶面Image Size

1.1-inch

800

0.010X

1289.2

966.9

焦距Focal length

8mm

700

0.011X

1133.3

850.0

光圈范围F No.

F1.4-16

600

0.013X

977.5

733.1

最短物距M.O.D(m)

0.1-Inf.

500

0.016X

821.6

616.2

控制方式Operation

Iris

Manual手动调整

400

0.019X

665.8

499.3

Focus

Manual手动调整

300

0.025X

509.9

382.5

视场角

Angle of View

(D×H×V)

1.1"

98.5°×84.8°×68.0°

200

0.036X

354.3

265.7

1"

89.5°×77.2°×61.8°

100

0.064X

199.2

149.4

2/3"

69.0°×57.6°×44.9°

-

-

-

-

畸变Distortion

<3%

-

-

-

-

光学后焦BFL

10.35mm

-

-

-

-

接口Mount

C-Mount

-

-

-

-

近摄视野Object Dimension

368.9mm×276.6mm(WD=300mm)

-

-

-

-

外形尺寸Dimension

Φ60×77.8mm

-

-

-

-

重量Weight

376.1g

-

-

-

-

滤镜尺寸Filter Thread

M58×P0.75mm

-

-

-

-

工作温度Working Temperature

-20ºC ～ +60ºC

-

-

-

-
