1000万像素75mm低畸变FA镜头C Mount

物距Working Distance

倍率Optical Magnification

视野   2/3"Field of View(mm)

型号Model

HM7528MP10

mm

X

H

V

像机尺寸Image Size

2/3-inch

3000

0.0255X

344.5

258.5

焦距Focal length

75mm

1500

0.0521X

168.73

126.61

光圈范围F No.

F2.8-16

1200

0.0659X

133.53

100.19

最短物距M.O.D(m)

0.4-Inf.

1000

0.0799X

110.10

82.61

控制方式Operation

Iris

Manual手动调整

850

0.0951X

92.55

69.43

Focus

Manual手动调整

700

0.1173X

75.04

56.29

视场角

Angle of View

(D×H×V)

2/3"

8.38°×6.71°×5.04°

600

0.1389X

63.36

47.53

1/2"

6.2°×4.91°×3.72°

500

0.1702X

51.72

38.80

1/3"

4.62°×3.71°×2.81°

450

0.1918X

45.91

34.44

畸变Distortion

<0.1%

400

0.2195X

10.11

30.09

光学后焦BFL

43.68mm

-

-

-

-

接口Mount

C-Mount

-

-

-

-

近摄视野Object Dimension

40.11mm×30.09mm (WD=400mm)

-

-

-

-

外形尺寸Dimension

Φ38×60.7mm

-

-

-

-

重量Weight

140.0g

-

-

-

-

滤镜尺寸Filter Thread

M30.5x 0.5

-

-

-

-

工作温度Working Temperature

-20ºC ～ +60ºC

-

-

-

-
