1000万像素12mm 低畸变FA镜头C Mount

物距Working Distance

倍率 Optical Magnification

视野 2/3"Field of View(mm)

型号Model

HM1228MP10

mm

X

H

V

像机尺寸Image Size

2/3-inch

5000

0.002X

3641.7

2731.7

焦距Focal length

12mm

2000

0.006X

1462

1096.5

光圈范围F No.

F2.8-16

1000

0.012X

735.4

551.5

最短物距M.O.D(m)

0.1-Inf.

900

0.013X

662.7

497.0

控制方式Operation

Iris

Manual手动调整

800

0.015X

590.0

442.5

Focus

Manual手动调整

700

0.017X

517.4

388.0

视场角

Angle of View

(D×H×V)

2/3"

48.5°×39.8°×30.4°

600

0.020X

444.7

306.3

1/2"

36.4°×29.5°×22.3°

550

0.022X

408.4

282.1

1/3"

27.7°×22.3°×16.8°

500

0.024X

372.0

279.0

畸变Distortion

<0.1%

450

0.026X

335.7

251.8

光学后焦BFL

13.8mm

400

0.029X

299.3

224.5

接口Mount

C-Mount

350

0.033X

263

197.2

近摄视野Object Dimension

226.6mm×170.4mm(WD=300mm)

300

0.039X

226.6

170.0

外形尺寸Dimension

Φ29×33.6mm

250

0.046X

190.2

142.7

重量Weight

54.3g

200

0.057X

153.8

115.4

滤镜尺寸Filter Thread

M27x 0.5

150

0.075X

117.4

88.0

工作温度Working Temperature

-20ºC ～ +60ºC

100

0.109X

80.7

60.3
