500万像素4mm低畸变FA镜头C Mount

物距Working Distance

倍率Magnification

视野   2/3"Field of View(mm)

型号Model

HM0428MP5

mm

-

H

V

像机尺寸Image Size

2/3-inch

1000

0.0042X

2138.39

1603.79

焦距Focal length

4mm

900

0.0046X

1928.91

1446.68

光圈范围F No.

F2.8-16

800

0.0052X

1719.43

1289.57

最短物距M.O.D(m)

0.06-Inf.

750

0.0055X

1614.69

1211.01

控制方式Operation

Iris

Manual手动调整

700

0.0059X

1509.94

1132.46

Focus

Manual手动调整

650

0.0063X

1405.20

1053.90

视场角

Angle of View

(D×H×V)

2/3"

106°×96.4°×79.8°

600

0.0068X

1300.46

975.35

1/2"

91.1°×78°×61.5°

550

0.0074X

1195.72

896.79

畸变Distortion

<3%

500

0.0081X

1090.98

818.24

光学后焦BFL

7.4mm

450

0.009X

986.24

739.68

接口Mount

C-Mount

400

0.01X

881.51

661.13

近摄视野Object Dimension

253mm×190mm(WD=100mm)

350

0.0114X

776.77

582.58

外形尺寸Dimension

Φ47×48.7mm

300

0.0131X

672.04

504.03

重量Weight

150g

250

0.0155X

567.31

425.48

分辨率Horizontal Resolution

5MP

200

0.0190X

462.59

346.94

滤镜尺寸Filter Thread

/

150

0.0247X

357.90

268.42

工作温度Working Temperature

-20ºC ～ +60ºC

100

0.0351X

253.29

189.96
