45MP Large Format Lens SK5028MP45 Sensor 1.4-inch 50mm F2.8 C-Mount: 1.4″ C-Mount f=50mm F2.8; High resolution,higher illumination relative; Low distortion,Can suppress stray light; Achromatic optical system design; Compatible with visible and near infrared

View phone

Inquiry now

Tel:+86 13570283679

Introduction Specifications Download Other Product

※ Product Features
◆ Brand：ZLKC
◆ Image Size：1.4″ C-mount
◆ Focal length：f=50mm
◆ F No.：F2.8-16
◆ Features：1.4-inch Large Format Lens 50mm 45MP Manual Iris Lens C Mount HD Lens

※ Model
SK5028MP45

※ Dimension

※ Industries Application
These are used in machine vision and ITS monitoring. Excellent vibration resistance and stability at high and low temperature performance, optical axis shifting within pixel level,Maintain excellent optical properties at different object distances. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras and so on

45MP 50mm Low distortion FA Lens C Mount			Working Distance	Magnification	1.4"Field of View(mm)
Model		SK5028MP45	mm	X	H	V
Image Size		1.4″(18.96x12.86mm)	2000	0.0256X	751.3	508.9
Focal length		50mm	1000	0.0524X	367.0	248.6
F No.		F2.8-16	900	0.0585X	328.6	222.6
M.O.D		0.25m	800	0.0663X	290.2	196.6
Operation	Iris	Manual	700	0.0764X	251.8	170.6
Operation	Focus	Manual	600	0.0901X	213.4	144.6
Angle of View (D×H×V)1.4"		25.8°×21.5°×14.7°	550	0.0990X	194.3	131.6
Distortion		<0.01%	500	0.1098X	175.1	118.6
BFL		23.5mm	450	0.1233X	156.0	105.7
Mount		C-Mount	400	0.1405X	136.9	92.7
Object Dimension		136.9mm×92.7mm(WD=400mm)	350	0.1633X	117.8	79.8
Dimension		Φ39.2×61.46mm	300	0.1948X	98.7	66.9
Filter Thread		M35.5xP0.5	250	0.2412X	79.8	54.0
Horizontal Resolution		45MP	-	-	-	-
Working Temperature		-20ºC ～ +60ºC	-	-	-	-

SK5028MP45 Specifications
