45MP 35mm Large Format Lens SK3528MP45 Sensor 1.4-inch F2.8 C-Mount: 1.4″ C-Mount f=35mm F2.8; High resolution,higher illumination relative; Low distortion,Can suppress stray light; Achromatic optical system design; Compatible with visible and near infrared

View phone

Inquiry now

Tel:+86 13570283679

Introduction Specifications Download Other Product

※ Product Features
◆ Brand：ZLKC
◆ Image Size：1.4″ C-mount
◆ Focal length：f=35mm
◆ F No.：F2.8-16
◆ Features：1.4-inch Large Format Lens 35mm 45MP Manual Iris Lens C Mount HD Lens

※ Model
SK3528MP45

※ Dimension

※ Industries Application
These are used in machine vision and ITS monitoring. Excellent vibration resistance and stability at high and low temperature performance, optical axis shifting within pixel level,Maintain excellent optical properties at different object distances. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras and so on

45MP 35mm Low distortion FA Lens C Mount			Working Distance	Magnification	1.4"Field of View(mm)
Model		SK3528MP45	mm	X	H	V
Image Size		1.4″(18.96x12.86mm)	2000	0.0175X	1085.2	736.0
Focal length		35mm	1000	0.0350X	542.2	367.8
F No.		F2.8-16	900	0.0389X	487.7	330.8
M.O.D		0.15m	800	0.0438X	433.4	294.0
Operation	Iris	Manual	700	0.0500X	379.2	275.2
Operation	Focus	Manual	600	0.0585X	326.9	221.6
Angle of View (D×H×V)1.4"		36.3°×30.4°×20.8°	550	0.0638X	279.6	201.8
Distortion		<0.01%	500	0.0702X	270.5	183.5
BFL		20.0mm	450	0.0780X	243.2	149.1
Mount		C-Mount	400	0.0867X	219.9	145.0
Object Dimension		216mm×146.4mm(WD=400mm)	350	0.1005X	188.8	128.1
Dimension		Φ38.2×62.7mm	300	0.1174X	161.6	109.6
Filter Thread		M34xP0.5	250	0.1413X	136.7	91.1
Horizontal Resolution		45MP	200	0.1773X	106.9	72.5
Working Temperature		-20ºC ～ +60ºC	150	0.2385X	79.5	53.9

SK3528MP45 Specifications
