45MP 16mm Large Format Lens SK1628MP45 Sensor 1.4-inch F2.8 C-Mount: 1.4″ C-Mount f=16mm F2.8; High resolution,higher illumination relative; Low distortion,Can suppress stray light; Achromatic optical system design; Compatible with visible and near infrared

View phone

Inquiry now

Tel:+86 13570283679

Introduction Specifications Download Other Product

※ Product Features
◆ Brand：ZLKC
◆ Image Size：1.4″ C-mount
◆ Focal length：f=16mm
◆ F No.：F2.8-16
◆ Features：1.4-inch Large Format Lens 16mm 45MP Manual Iris Lens C Mount HD Lens

※ Model
SK1628MP45

※ Dimension

※ Industries Application
These are used in machine vision and ITS monitoring. Excellent vibration resistance and stability at high and low temperature performance, optical axis shifting within pixel level,Maintain excellent optical properties at different object distances. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras and so on

45MP 16mm Low distortion FA Lens C Mount			Working Distance	Magnification	1.4"Field of View(mm)
Model		SK1628MP45	mm	X	H	V
Image Size		1.4″(18.96x12.86mm)	2000	0.0080X	2384.0	1616
Focal length		16mm	1000	0.0158X	1201.2	813.6
F No.		F2.8-16	900	0.0176X	1083.2	733.6
M.O.D		0.15m	800	0.0197X	964.4	653.2
Operation	Iris	Manual	700	0.0225X	846.4	573.2
Operation	Focus	Manual	600	0.0262X	728.0	492.8
Angle of View (D×H×V)1.4"		71.3°×61.4°×43.8°	550	0.0285X	668.8	452.8
Distortion		<0.5%	500	0.0312X	609.2	412.8
BFL		11.7mm	450	0.0346X	550.4	372.8
Mount		C-Mount	400	0.0388X	450.8	332.4
Object Dimension		372.6mm×252.2mm(WD=300mm)	350	0.0441X	432.0	292.4
Dimension		Φ49×67.83mm	300	0.0511X	372.8	252.4
Filter Thread		M46xP0.75	250	0.0608X	313.2	212.0
Horizontal Resolution		45MP	200	0.0750X	254.0	172.0
Working Temperature		-20ºC ～ +60ºC	150	0.0979X	194.8	131.6

SK1628MP45 Specifications
