45MP 25mm Large Format Lens SK2528MP45 Sensor 1.4-inch F2.8 C-Mount: 1.4″ C-Mount f=25mm F2.8; High resolution,higher illumination relative; Low distortion,Can suppress stray light; Achromatic optical system design; Compatible with visible and near infrared

View phone

Inquiry now

Tel:+86 13570283679

Introduction Specifications Download Other Product

※ Product Features
◆ Brand：ZLKC
◆ Image Size：1.4″ C-mount
◆ Focal length：f=25mm
◆ F No.：F2.8-16
◆ Features：1.4-inch Large Format Lens 25mm 45MP Manual Iris Lens C Mount HD Lens

※ Model
SK2528MP45

※ Dimension

※ Industries Application
These are used in machine vision and ITS monitoring. Excellent vibration resistance and stability at high and low temperature performance, optical axis shifting within pixel level,Maintain excellent optical properties at different object distances. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras and so on

45MP 25mm Low distortion FA Lens C Mount			Working Distance	Magnification	1.4"Field of View(mm)
Model		SK2528MP45	mm	X	H	V
Image Size		1.4″(18.96x12.86mm)	2000	0.0124X	1524.6	1034
Focal length		25mm	1000	0.0248X	766.0	519.6
F No.		F2.8-16	900	0.0275X	690.2	468.2
M.O.D		0.15m	800	0.0309X	614.4	416.6
Operation	Iris	Manual	700	0.0352X	538.4	365.2
Operation	Focus	Manual	600	0.0410X	462.6	313.8
Angle of View (D×H×V)1.4"		49.2°×41.6°×28.9°	550	0.0447X	424.6	288.0
Distortion		<0.01%	500	0.0490X	386.8	262.2
BFL		17.2mm	450	0.0544X	348.8	236.6
Mount		C-Mount	400	0.0610X	310.8	210.8
Object Dimension		234.8mm×159.2mm(WD=300mm)	350	0.0695X	272.8	185.0
Dimension		Φ45.6×73.1mm	300	0.0807X	234.8	159.2
Filter Thread		M43xP0.5	250	0.0963X	196.8	133.6
Horizontal Resolution		45MP	200	0.1194X	158.8	107.8
Working Temperature		-20ºC ～ +60ºC	150	0.1571X	120.8	81.8

SK2528MP45 Specifications
