Model

FM12036MP5

Image Size

2/3-inch（8.8mm×6.6mm）

Focal length

12-36mm

F No.

F2.8-16

M.O.D(m)

0.1-Inf.

Operation

Iris

Manual

Focus

Manual

Zoom

Manual

Horizontal Angle of View

2/3"Type

W:49.2°×40.3°×30.8° T:17.2°×13.8°×10.5°

1/1.8"Type

W:40.5°×33°×25° T:14°×11.3°×8.4°

1/2"Type

W:36.9°×30°×22.6° T:12.6°×10.1°×7.6°

Distortion

2/3"Type

W：-2.0%@y=5.5mm T：0.95%@y=5.5mm

Back focal length

10.05mm

Mount

C-Mount

Dimension

Ф41x63.1mm

Weight

158.0g

Horizontal Resolution

150lp/mm

Filter Thread

M37.5x 0.5

Working Temperature

-20ºC ～ +60ºC
